C1.5 Diesel Engine Assembly for CATERPILLAR Excavator

C1.5 Diesel Engine Assembly for CATERPILLAR Excavator

Get Latest Price

Payment Type:	L/C,T/T,D/P,D/A,Paypal
Incoterm:	FOB,EXW
Min. Order:	1 Piece/Pieces
Transportation:	Ocean,Land,Express,Air
Port:	Guangzhou Huangpu

Applicable brand:

CATERPILLAR

Contact Now

Product Description

Product Attributes

Model No.: C1.5 (18.4 KW)

Status: New

Applicable Industry: Construction Works, Energy &Amp; Mining

Out-of-warranty Service: Online Support

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None

Showroom Location (in Which Countries Are There Sample Rooms Overseas): None

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: Ordinary Product

Place Of Origin: China

Warranty Period: 1 Year

Service System: Online Support

Maximum Torque: 86 Nm @ 1800 rpm

Rated Speed: 2200/2800 rpm

Minimum Power: 18.4 KW

Emission: US EPA Tier 4 Final

Engine Configuration: Inline 3-cylinder

Cylinder Diameter: 84 mm

Stroke: 90 mm

Net Weight: 148 KG

Maximum Power: 18.4 KW

Displacement: 1.496 l

Packaging & Delivery

Selling Units	:	Piece/Pieces
Package Type	:	Wooden
Picture Example	:

The file is encrypted. Please fill in the following information to continue accessing it

ISUZU ENGINE ASSY

JIUWU POWER Excavator Spare Part



Product Description

Product description

The C1.5 engine assembly is the core component of this roller, with high performance and stability.The C1.5 engine assembly has various spare parts, including cylinder block, crankshaft, Cylinder Head, piston, connecting rod, valve system, fuel system, lubrication system, cooling system, etc. These spare parts must be replaced or repaired regularly to ensure the normal operation of the engine assembly.

Product Parameters

Rated power
Maximum Power	18.4 KW
Maximum Torque	86 Nm @ 1800 rpm
Rated Speed	2200/2800 rpm
Minimum Power	18.4 KW
Emission standard
Emissions	US EPA Tier 4 Final
Currency
Engine Configuration	Inline 3-cylinder
Cylinder Diameter	84 mm
Stroke	90 mm
Displacement	1.496 l
Compression Ratio	22.5:1
Air Intake Method	Natural intake (NA)
Combustion System	Indirect Fuel Injection
Rotation Direction (Viewed From The Flywheel End)	Counterclockwise
Engine Size - Approximate Values
Length	572 mm
Width	453 mm
Height	643 mm
Net Weight	148 kg
Whatsappp	18319626398

Product Details

CATERPILLAR EXCAVATOR PART operates well within a range of minutes,The magnificent power of these engines is suitable for the extraordinary packaging of all kinds of options.A wide range of external programs on the road. fixing and maintaining a kind of service, helping to improve conservation easily.reduce the total operating costs for equipment holders.
