C0.7 Industrial Diesel Engine Assy for Caterpillar Excavator

C0.7 Industrial Diesel Engine Assy for Caterpillar Excavator

Get Latest Price

Payment Type:	L/C,T/T,D/A,Paypal,D/P
Incoterm:	FOB,EXW
Min. Order:	1 Piece/Pieces
Transportation:	Ocean,Land,Air,Express
Port:	Guangzhou Huangpu

Applicable brand:

CATERPILLAR

Contact Now

Product Description

Product Attributes

Model No.: C0.7 15.3 KW

Status: New

Applicable Industry: Construction Works, Energy &Amp; Mining

Out-of-warranty Service: Online Support

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None

Showroom Location (in Which Countries Are There Sample Rooms Overseas): None

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: Ordinary Product

Place Of Origin: China

Warranty Period: 1 Year

Service System: Online Support

Maximum Power: 15.3 KW

Maximum Torque: 50.4 Nm @ 2400 rpm

Rated Speed: 2800-3600 rpm

Minimum Power: 12.2 KW

Emission: US EPA Tier 4 Interim Equivalent Standards

Cylinder Diameter: 67 mm

Stroke: 72 mm

Net Weight: 71 KG

Engine Configuration: Inline three cylinder four stroke diesel engine

Displacement: 0.762 l

Packaging & Delivery

Selling Units	:	Piece/Pieces
Package Type	:	Wooden
Picture Example	:

The file is encrypted. Please fill in the following information to continue accessing it

excavator spare parts supplier



Product Description

CATERPILLAR ENGINE ASSY

The C0.7 Industrial Diesel Engine Assy is a compact and powerful engine designed for use in Caterpillar excavators. This engine features a displacement of 0.7 liters and is capable of producing up to 18.4 horsepower at 3,000 RPM. It also boasts a torque output of 40 Nm at 2,000 RPM.

The C0.7 Industrial Diesel Engine Assy is designed with durability in mind, featuring a cast iron block and Cylinder Head for increased strength and longevity. It also includes a high-pressure common rail fuel system for improved fuel efficiency and reduced emissions.

This engine is designed to meet Tier 4 Final emissions standards, making it an environmentally-friendly choice for industrial applications. It also includes a number of features to improve operator comfort and safety, including low noise and vibration levels and an automatic shutdown system in the event of low oil pressure or high coolant temperature.

Overall, the C0.7 Industrial Diesel Engine Assy is a reliable and efficient choice for use in Caterpillar excavators, providing the power and performance needed for a wide range of industrial applications.
CATERPILLAR C0.7

Rated power
Maximum Power	15.3 KW
Maximum Torque	50.4 Nm @ 2400 rpm
Rated Speed	2800-3600 rpm
Minimum Power	12.2 KW
Emission standard
Emissions	US EPA Tier 4 Interim Equivalent Standards
Currency
Engine Configuration	Inline three cylinder four stroke diesel engine
Cylinder Diameter	67 mm
Stroke	72 mm
Displacement	0.762 l
Compression Ratio	23.5:1
Air Intake Method	Natural intake (NA)
Combustion System	Indirect Fuel Injection
Rotation Direction (Viewed From The Flywheel End)	Counterclockwise
Engine Size - Approximate Values
Length	480 mm
Width	371 mm
Height	528 mm
Net Weight	71 kg
